ENPOLY™-AOP

ENPOLY™-AOP

ENPOLY™-AOP

Contact

Overview

  1. High-output UV lamps enable large-capacity treatment with fewer lamps
  2. Broader UV wavelength distribution and higher UV intensity compared to low-pressure UV lamps
  3. Comprehensive features including automatic cleaning system, UV monitoring, energy-saving operation mode, remote control, and system surveillance
  4. Versatile applications: water purification, wastewater disinfection, ultrapure water, desalination, ozone removal, alcoholic beverages, soft drinks, bottled water, and swimming pool
Model Name ENPOLY™-AOP
Chamber
Chamber Configuration

Inline

U-type
Chamber Material STS316 / 316L
Internal Finish 전해연마
Design Pressure 10 ~ 15 bar
Lamp
Lamp Type Medium Pressure UV Lamp

Gallery

How It Works

UV AOP is a process that generates radicals (typically OH radicals) using ultraviolet light and oxidizers to oxidize and decompose organic contaminants in water.

Medium-pressure UV AOP uses medium-pressure lamps capable of irradiating multiple UV wavelengths to remove various organic pollutants. This enables large-capacity water treatment with fewer lamps.

Benefits

  1. Minimized footprint (approximately 70% reduction compared to low-pressure UV systems)
  2. Easy maintenance due to fewer reactors and lamps
  3. Performance verified through CFD-RED analysis and extensive field testing
  4. Superior UV intensity and broader wavelength range compared to low-pressure UV lamps
  5. Lower initial investment cost compared to low-pressure UV system

Applications

Pure & Ultrapure Water

Potable Water

Remediation

Wastewater

Water Reuse
